Well-designed Laser Q Switch Tattoo Removal - [Copy] Platform Series-HS-900 – Apolo

Short Description:

Product Detail

Related Video

Our rewards are reduce selling prices,dynamic revenue team,specialized QC,sturdy factories,superior quality services for Portable Red Light Pdt Led Therapy Light , Portable Red Light Pdt Led Therapy Light , Picosecond Nd Yag Partable , On account of superior quality and competitive price , we will be the market leader, please don’t hesitate to contact us by phone or email, if you are interested in any of our products.

Well-designed Laser Q Switch Tattoo Removal - [Copy] Platform Series-HS-900 – Apolo Detail:

TECHNICAL SPECIFICATION

	Handpiece	2940nm Er:YAG fractional ablative laser
	Spot size	10x10mmΦ6mm, Φ9mm, Φ1-3.4mm
	Energy	7x7 pixel: 12-28mJ/MTZ9x9 pixel: 4-20mJ/MTZBeam expander: 500-2000mJZoom lens: 500-2000mJ
	Pulse width	1.5ms, 2ms, 2.5ms
	Handpiece	1540nm Er:Glass fractional laser
	Energy	10x10 pixel: 30-70mJ/MTZ18x18 pixel: 5-25mJ/MTZ
	Pulse width	10ms, 15ms
	Handpiece	1064nm Long Pulse ND:YAG Laser
	Pulse width	10-40ms
	Repetition rate	0.5-1Hz
	Energy density	Φ9mm: 10-110J/cm2Φ6mm: 60-260J/cm2Φ2.2*5mm: 150-500J/cm2
	Handpiece	1064/532nm Q-switch ND:YAG Laser
	Spot size	1-5mm
	Pulse width	＜10ns (single pulse)
	Repetition rate	1-10Hz
	Max. Energy	2400mJ-4700mJ
	Handpiece	IPL SHR/EPL
	Spot size	15*50mm
	Wavelength	420-1200nm
	Filter	420/510/560/610/640-1200nm, SHR filter
	Energy	10-60 level
	Handpiece	RF Monopolar or RF Bipolar
	Output power	200W
	RF tip	Φ18mm, Φ28mm, Φ37mm
	Operate interface	8’ true color touch screen
	Dimension	6548115cm (LWH)
	Weight	72Kgs

ADVANTAGES

TUV Medical CE approved

Handpieces interchangeable and auto-detected

Numerous aesthetic/medical applications

High output energy for amazing efficacy

Smart software upgradable

High patient and clinical staff satisfaction

Product detail pictures:

We believe in: Innovation is our soul and spirit. High-quality is our life. Consumer need to have is our God for Well-designed Laser Q Switch Tattoo Removal - [Copy] Platform Series-HS-900 – Apolo, The product will supply to all over the world, such as: Czech republic , San Francisco , Uruguay , Our company has already have pass the ISO standard and we're fully respect our customer 's patents and copyrights. If the customer provides their own designs, We will guarantee that they will likely be the only one can have that merchandise. We hoping that with our good products can bring our customers a great fortune.
